S84-ex SERIES

The S84-ex and S86-ex offer significant industry advancements in quality imaging, exceptional throughput, and incomparably easy operation, setup and maintenance. The new generation of SATO print engines delivers flexibility and convenience, providing customers with numerous interfaces as well as tool-less maintenance, and optional wireless LAN and Bluetooth allow for even greater connectivity in continuously changing […]

Contact Us Download Brochure

The S84-ex and S86-ex offer significant industry advancements in quality imaging, exceptional throughput, and incomparably easy operation, setup and maintenance. The new generation of SATO print engines delivers flexibility and convenience, providing customers with numerous interfaces as well as tool-less maintenance, and optional wireless LAN and Bluetooth allow for even greater connectivity in continuously changing operating environments.

Print Method:
Thermal Transfer model
Direct Thermal only model

Print Width:
104 mm (4.1″)

Media Width:
13 mm – 131 mm
(0.51″ – 5.16″)

Print Speed (max.):
406 mm/s (16 ips) – 203 dpi
356 mm/s (14 ips) – 305 dpi
152 mm/s (6 ips) – 609 dpi

Resolution:
8 dot/mm – 203 dpi
12 dot/mm – 305 dpi
24 dot/mm – 609 dpi

Memory:
48MB Flash ROM
64 MB SDRAM

Standard Interfaces:
USB-USB Host-LAN-RS232C – IEEE1284-EXT (IO)- SD Card

Optional Interfaces:
WLAN – Bluetooth
